ASI 8374 Automatic Roll Towel Dispenser Mechanism
The ASI 8374 is the touchless dispensing mechanism for compatible ASI roll-towel cabinets; it is not a complete cabinet. It is intended for projects that need the internal feed mechanism while retaining or separately specifying the dispenser enclosure.
Capacity and Operation
- Accepts one 8-inch-wide roll up to 8 inches in diameter and 800 feet long
- Also holds one 8-inch-wide stub roll up to 4 inches in diameter
- Sensor-activated, one-length-at-a-time dispensing
- Owner-adjustable length, delay, and paper-saver settings
- Automatic transfer from the stub roll to a newly loaded full roll
- Internal towel cut-off bar and LED sensing/battery indicator
Power and Installation
Power requires four D-size batteries, not included, or the optional ASI 72-ACA low-voltage adapter, sold separately. Confirm cabinet compatibility before ordering. The mechanism mounts to the cabinet back through the supplied mounting slots and the cabinet’s threaded mechanism holes.
