Stiebel Eltron CE Plus 72 kW (480V Delta) 3-Phase Commercial Tankless Water Heater
The Stiebel Eltron CE Plus 72 kW (480V Delta) represents the ultimate in high-voltage industrial water heating, specifically engineered for massive thermal loads in large-scale commercial and industrial facilities. Designed for 480V 3-phase Delta electrical architectures, this model (Part Number: CE-Plus-072-480) operates with a class-leading 99% energy efficiency rating. By delivering voluminous hot water instantaneously, it eliminates the energy-draining standby cycles and expansive footprint required by traditional industrial storage tanks and boiler systems.
Performance & Electrical Specifications
The CE Plus 72 kW leverages high-voltage efficiency to provide extreme temperature rises, making it the premier choice for heavy-duty process heating, large-scale commercial kitchens, and high-demand industrial sanitation.
- Power Output: 72.00 kW at 480V.
- Amperage: 86.60 Amps.
- Breaker Requirement: 100A (3-Pole).
- Temperature Rise Capability:
- 491°F rise at 1 gpm.
- 246°F rise at 2 gpm.
- 164°F rise at 3 gpm.
- 123°F rise at 4 gpm.
- Activation Rate: An ultra-low minimum activation flow of 0.7 gpm ensures seamless performance even when paired with high-efficiency sensor faucets or low-flow fixtures.
- Maximum Flow Rate: Robust internal fluidics support high-capacity facility requirements up to 10.6 gpm at 60 psi.
Industrial-Grade Engineering & Durability
- 316L Stainless Steel Architecture: Every unit is constructed with a high-grade 316L stainless steel heat exchanger and internal plumbing to provide maximum resistance to chemical corrosion and thermal stress.
- Direct Coil™ Heating Technology: This proprietary design features heating elements that vibrate slightly during operation to mechanically prevent the buildup of limescale and mineral deposits. This self-cleaning action ensures peak thermal transfer and longevity in harsh industrial environments.
- Advanced Flow Control™: Integrated microprocessor technology automatically modulates water flow to maintain a precise output temperature if the facility's instantaneous demand exceeds the unit's 72 kW heating capacity.
- NEMA Rated Protection: The unit comes standard in a NEMA 3 enclosure. For specialized industrial facilities, optional NEMA 4 and 4X (Stainless Steel) enclosures are available for wash-down ratings or corrosive atmospheres.
- Comprehensive Safety Protocols: Equipped with four independent levels of over-temperature protection, an automatic internal air vent, and a lead-free brass pressure relief valve.
Compliance & Quality Assurance
- Safety Standards: Certified to ANSI/UL Std. 499 and conforms to CAN/CSA Std. C22.2 No. 88.
- Lead-Free Compliance: Tested and certified by the WQA against NSF/ANSI/CAN 372 for lead-free construction.
- Industrial Warranty: Protected by a 6-year warranty against leakage and a 2-year warranty on all components and materials.
- Manufacturing: Proudly manufactured in the USA.
Maximize your facility's operational efficiency with the high-voltage power of the Stiebel Eltron CE-Plus-072-480. Secure the best price or request a professional volume quote today at ProDryers or call 888-503-7937 for expert technical assistance.
Download the C Series Commercial Options List
