Stiebel Eltron CE Plus 24 kW (240V Delta) 3-Phase Commercial Tankless Water Heater
The Stiebel Eltron CE Plus 24 kW (240V Delta) is a high-capacity, industrial-grade thermal solution engineered specifically for demanding point-of-use or multipoint applications in commercial environments. Utilizing a 240V 3-phase Delta configuration, this model (Part Number: CE-Plus-024-240) provides a continuous, instantaneous supply of hot water while maintaining near-perfect 99% energy efficiency. By eliminating the standby heat losses common in traditional tank systems, it significantly reduces operational overhead for facilities with high hot water demands.
Performance & Electrical Specifications
Designed to withstand the rigorous demands of commercial facilities, the CE Plus series integrates advanced microprocessor controls and self-cleaning heating technology.
- Power Output: 25.00 kW at 240V.
- Amperage: 60.14 Amps.
- Breaker Requirement: 70A (3-Pole).
- Temperature Rise:
- 171°F rise at 1 gpm.
- 85°F rise at 2 gpm.
- 57°F rise at 3 gpm.
- Activation Rate: Minimum activation flow of 0.7 gpm, perfectly suited for high-efficiency commercial fixtures.
- Max Flow Rate: Supports high-demand requirements up to 10.6 gpm at 60 psi.
Engineering & Durability
- 316L Stainless Steel Heat Exchanger: Constructed with premium 316L stainless steel for both the heat exchanger and pipe connections, providing superior resistance to chemical corrosion, thermal fatigue, and high-pressure stress.
- Direct Coil™ Heating System: Features a specialized heating element design that vibrates during operation to actively prevent the accumulation of limescale and mineral deposits, ensuring long-term reliability in hard water areas.
- Advanced Flow Control™: Exclusive technology that automatically maintains consistent output temperatures by adjusting water flow if the total demand exceeds the unit’s maximum heating capacity.
- Industrial Protection: Standardized in a NEMA 3 enclosure. Optional NEMA 4 and 4X (Stainless Steel) enclosures are available for facilities requiring wash-down ratings or protection in highly corrosive environments.
- Multi-Level Safety: Equipped with four independent levels of over-temperature protection, an automatic internal air vent, and a lead-free brass pressure relief valve.
Compliance & Quality Assurance
- Standards: Certified to ANSI/UL Std. 499 and conforms to CAN/CSA Std. C22.2 No.88.
- Lead-Free Compliance: Tested and certified by the WQA against NSF/ANSI/CAN 372 for lead-free construction.
- Warranty: Protected by a 6-year leakage warranty and a 2-year warranty on all parts and materials.
- Origin: Proudly manufactured in the USA.
Secure the best price for your commercial facility or request a professional volume quote today. Shop the Stiebel Eltron CE-Plus-024-240 online at ProDryers or call 888-503-7937 for expert technical assistance.
Download the C Series Commercial Options List
