ASI 645210AC-41 Piatto Completely Recessed Automatic Roll Paper Towel Dispenser
The ASI 645210AC-41 is an AC-powered, proximity-sensing dispenser designed to sit completely flush with the finished wall. Its matte black phenolic door and concealed hardware distinguish this Piatto model; it holds an 8-inch-wide main roll and an 8-inch-wide stub roll for automatic changeover when the feed tabs are properly engaged.
Capacity and construction
- Holds one standard roll up to 8 inches in diameter and 800 feet long, plus one stub roll up to 4 inches in diameter.
- Type 304 stainless steel frame with matte black phenolic door; metal hardware is concealed.
- Field-adjustable furniture-style hinges and an internal spring-loaded door latch.
- Owner-selectable towel length, delay, and paper-saver settings; dispensing activates when hands enter the sensor zone.
- Dimensions: 16-1/16 inches wide x 28 inches high x 9-13/16 inches deep.
Recessed installation and servicing
Plan for a finished wall opening at least 16-1/8 inches wide x 28-1/16 inches high x 10 inches deep. The manufacturer specifies mounting the unit flush to the wall; its installation guidance for 2010 ADA Accessibility Standards calls for the towel outlet to be no more than 48 inches above the finished floor. AC supply wiring and a duplex outlet are provided by others; the supplied adapter plugs into that outlet. Open the door to replace an empty or partially used roll. For automatic changeover to the main roll, engage the stub-roll feed tabs properly. The manufacturer lists a one-year warranty from invoice date.
Made to order: ASI Piatto products are not returnable.
