ASI 1307-6 Utility Hook Strip, 6 Hooks, Surface Mounted
The ASI 1307-6 is a surface-mounted utility hook strip with six hooks across a 56-inch length. Its 20-gauge Type 304 stainless steel construction and satin finish distinguish the product; confirm the overall dimensions and wall reinforcement before specifying the installation.
Specifications
- Six hooks; 56 inches wide.
- 20-gauge Type 304 stainless steel with satin finish.
- Surface mounted; the product overview describes a 4-inch-high strip with 1/2-inch returns to the wall.
- Overall dimensions: 56 inches W x 9-3/4 inches H x 2-3/16 inches D.
- Manufacturer-stated warranty: one year from invoice date.
Mounting guidance
For general utility use, ASI recommends mounting the unit 72 inches above finished floor (AFF), measured from the centerline of the mounting holes. For the manufacturer's guidance referencing the 2010 ADA Accessibility Standards, install with the top of a hook no higher than 48 inches AFF; this is installation guidance, not a blanket compliance determination. Use #10 self-threading pan-head screws through the strip's mounting holes into suitable anchors, blocking, or other wall reinforcement. Screws and reinforcement are by others and must support the intended load when all hooks are used.
Rags and towels are placed on the hooks as needed.
