ASI 0473-1A Surface-Mounted Sanitary Napkin Disposal
This unit is intended for end-stall installation and holds 1.5 gallons (5.7 L) of dry/solids waste. The cabinet, door, flanges, and waste receptacle are 22-gauge Type 304 stainless steel with a satin finish.
Users push the door to deposit waste; a stainless steel spring hinge closes it. For service, unlock the unit, remove the bottom receptacle, and invert it over a collection bag. An internal angle captures the receptacle, while the lock helps prevent unauthorized removal. The safety-edged finger grip assists with handling during emptying.
Installation and servicing
Surface-mount to the wall using #10 self-threading screws, which are not included. The unit measures 11" W x 4" D x 15-1/4" H. Set the waste-removal schedule according to maintenance needs; the waste container must be emptied manually.
