ASI 04692AC-9 Surface-Mounted Automatic Roll Paper Towel Dispenser and Waste Receptacle
The ASI 04692AC-9 combines a no-touch automatic roll towel dispenser and a 17-gallon waste receptacle in a surface-mounted unit with a 9-inch collar. It accepts 8- or 9-inch-wide standard rolls up to 800 feet long and supports stub rolls.
Specifications
- Dispenses a preset towel length when hands enter the sensor zone; towels dispense one at a time.
- 17-gallon (64 L) removable waste receptacle, emptied manually according to maintenance needs.
- 22-gauge Type 304 stainless steel cabinet, frame, and waste container with satin finish; double-pan door with fiberboard filler and stainless steel piano hinge.
- Overall dimensions: 17-1/4 in. W x 56 in. H x 10-1/4 in. D.
- Supplied adapter uses 110–240 VAC, 50/60 Hz input and provides 6 VDC at 2 A output.
Installation and operation
Mount the unit to suitable wall preparation using the concealed mounting holes; mounting screws are by others. ASI's installation guidance states that, for compliance with the 2010 ADA Accessibility Standards, the bottom edge of the towel dispenser door should be no more than 48 in. above the finished floor. Power is brought to the rear of the unit and connected to a simplex outlet inside the cabinet. The manufacturer specifies a 110–240 VAC supply on a 15 A circuit breaker; the outlet and wiring or conduit are by others.
When a partial roll remains, loading a full roll allows dispensing to resume automatically after the partial roll is used. The locking compartment and receptacle retainer help prevent unauthorized access and removal.
Warranty: One year from the invoice date.
