ASI 04692-9 Traditional Surface-Mounted Roll Paper Towel Dispenser and Waste Receptacle
The ASI 04692-9 is a surface-mounted combination dispenser and waste receptacle for commercial restrooms where a wall recess is not the selected installation. Its removable receptacle holds 18 gallons.
Specifications and operation
- Overall dimensions: 17-1/4 inches W x 56 inches H x 11-3/4 inches D; check available wall space before installation.
- Dispenses standard 8- or 9-inch-wide towel rolls up to 800 feet long and accepts a stub roll for continued dispensing.
- Lever-operated feed continues until the towel supply is depleted. The supplied pin limits lever stroke to adjust towel-feed length; a full roll loaded while a partial roll remains starts automatically after the partial roll is finished.
- Type 304 stainless steel with a satin finish; surface mounted with the -9 collar.
- The locking compartment and receptacle retainer prevent unauthorized access or removal.
Installation and servicing
Install on the wall using four #10 self-threading screws through the concealed mounting holes; screws are by others. The suggested lever-handle mounting height is 55 inches above finished floor. The manufacturer directs users seeking reduced-height installation with a 6-inch curb and 2010 ADA Accessibility Standards guidance to Models 0463 or 046921 series; this is installation guidance, not a blanket compliance claim.
Refill the towel roll as needed and empty the waste receptacle manually according to maintenance needs.
