ASI 0393-6-1AC-41 EZ-Fill Top-Fill Multi-Feed Foam Soap Dispenser Heads, 6-Pack
The ASI 0393-6-1AC-41 is a six-pack of matte black, vanity-mounted automatic foam soap dispenser heads with AC adapter operation. It suits installations using the separately purchased EZ-Fill Multi-Feed tank and kit, which can supply up to six dispensers; one remote control is supplied with the six-pack. The top-fill system lets staff replenish soap from above the vanity.
Key specifications and setup
- Power: AC adapter operation; the manufacturer specifies a GFCI outlet under the vanity within 13.5 ft of the pump assembly.
- System components: Multi-Feed tank and kit are sold separately. Up to six heads can draw from the tank.
- Soap: Use clear foaming liquid with viscosity of 1–100 cP and pH of 5.5–8.5. Avoid soaps containing reportable salts, chlorides, or alcohols.
- Remote: The included remote can prime the system and program alternate dispense amounts.
- Installation planning: Allow under-vanity space for the pump and compressor, and position the sensor so it does not face a mirror or another infrared sensor. Keep the sensor clear of the nearby faucet's water stream.
- Maintenance: Clean the compressor filter every six months as recommended by the manufacturer; keep the soap container clean to help prevent clogging.
After filling the Multi-Feed tank, prime with the pump's manual fill button or the remote. The manufacturer recommends cleaning the dispenser surface with soap and water, then drying it with a clean cloth.
ASI 0393-6-1AC-41 EZFill Foam Soap Dispenser Spec Sheet
ASI EZ-Fill Soap Dispensing System Installation Guide
