ASI 0264-12 Double Toilet Tissue Holder, Theft-Resistant
The ASI 0264-12 is a surface-mounted double toilet tissue holder for two standard-core rolls up to 6 in. (152 mm) in diameter; the manufacturer lists 2,000-sheet capacity. Its theft-resistant spindles are secured by concealed locking screws.
Capacity, construction and operation
- Heavy-duty cast aluminum body with a satin matte silver-grey finish.
- Two independent, no-waste rocking-action spindles made of impact-resistant ABS thermoplastic; each turns one-half revolution per operation and returns to position.
- The roll core blocks access to the release pin, so a roll cannot be removed until exhausted; the concealed locking screw can be loosened only with a key.
- For replenishment, release the concealed pin to operate the spindle's spring lock and free the spindle.
- Overall dimensions: 13 in. W x 1-3/4 in. H x 4-3/4 in. D.
Installation
Mount to a wall or partition with #10 self-threading screws, which are not included. The manufacturer's guidance referencing the 2010 ADA Accessibility Standards specifies a tissue-roll centerline between 19 in. minimum and 44 in. maximum above the finished floor (AFF). Confirm placement for the project. The manufacturer lists a one-year warranty from the invoice date.
