ASI-0030-41 Matte Black Dual-Roll Toilet Tissue Dispenser
This surface-mounted dispenser holds two rolls up to 5 1/4" (133 mm) in diameter, with up to 1,800 sheets per roll. When the bottom roll is depleted, the top roll automatically drops into position. The Type 304 stainless steel cabinet and mechanism have a powder-coated matte black finish, and theft-resistant spindles help secure the rolls.
The cabinet measures 6" W x 12" H x 6 1/2" D. Installation uses four 1/4" x 1" (M6 x 25) screws through the rear mounting slots; screws and suitable wall preparation are by others. The manufacturer’s installation guidance specifies the bottom roller axis at 15"–48" above finished floor and the dispenser centerline 7"–9" in front of the toilet. This is manufacturer guidance, not a blanket compliance determination.
Reloading and service
Reloading instructions are printed inside the door. Empty rollers cannot be removed without unlocking the door with the key. Manufacturer warranty: one year from invoice date.
