ASI 7345-B Double Surface-Mounted Robe Hook
The ASI 7345-B is a surface-mounted double robe hook with a bright finish. Its 4-inch-wide stainless steel bar forms a hook at each end, projects 2 inches from the wall, and is suitable for robes, clothing and small carry bags.
Specifications and installation
- Dimensions: 4 in. W × 2 in. H × 2 in. D (102 × 51 × 51 mm).
- Mount on a wall or the back of a door using two #10 self-threading screws (supplied by others) through the mounting plate into suitable prepared mountings or other suitable hardware for the surface.
- Hang the post and flange assembly on the mounting plate, then tighten the set screw to lock it in place.
- Manufacturer installation guidance: top of hook at 48 in. (1219 mm) maximum above finished floor (AFF); 46 in. (1168 mm) maximum for the specified side-reach condition over an obstruction, or 44 in. (1118 mm) maximum for the specified forward-reach condition over an obstruction. For general utility, the guidance gives 68 in. (1727 mm) AFF to the centerline of the mounting plate. Refer to the manufacturer's instructions for the obstruction conditions.
- Manufacturer-stated warranty: one year from invoice date.
