ASI 645224AC-9 Simplicity Automatic Roll Paper Towel Dispenser
The ASI 645224AC-9 is a surface-mounted, AC-powered, automatic roll towel dispenser with a stainless steel satin-finish cabinet. A proximity sensor starts dispensing when hands enter the sensor zone. The unit holds one standard roll and has stub-roll capability for continued dispensing.
Capacity and operation
- Standard roll: 8 inches wide, up to 8 inches in diameter and 800 feet long. The manufacturer also lists 9-inch-wide standard rolls up to 800 feet.
- Stub roll: 8 inches wide and up to 4 inches in diameter.
- Three three-position switches let the owner set towel length, delay, and economy. An LED indicates sensing and operation.
- When reloading with a full roll, transfer the partial roll to the stub-roll position so dispensing can continue.
Installation and dimensions
The cabinet and frame are Type 304 stainless steel with a satin finish. The dispenser is surface mounted using the -9 stainless steel collar, which slides onto the cabinet back before wall installation. The supplied low-voltage adapter accepts 110–240 VAC, 50/60 Hz and provides 6 VDC at 2 A. The manufacturer specifies installing the top of the towel opening no higher than 48 inches above the finished floor for its cited accessibility guidance. Overall dimensions are 17-1/4 inches wide x 30-1/2 inches high x 9-7/8 inches deep. The manufacturer lists a one-year warranty from invoice date.
