ASI 39 Drywall Mounting Clamp
This No. 20 gauge corrosion-protected steel clamp has universal mounting slots for the listed ASI units. Self-tapping screws are supplied separately with the specified unit. Dimensions: 6-11/16" x 4-1/2" x 1-7/8" (170 x 114 x 48 mm).
For use with ASI Models 0402-DZ, 0404-DZ, 0406-DZ, 0410-DZ, 7402-D, 7402-HD, 74022-D, 74022-HD, 7404-D, 7406-D, and 7410-D.
Installation
Provide the appropriate wall opening. Loosely attach the clamp to the back of the unit with the screws provided, insert it into the opening, and adjust it to grip the inside wall surface. Tighten the screws to secure it.
