ASI 20363 Roval Surface-Mounted Push-Button Liquid Soap Dispenser
The ASI 20363 is a 57 oz. surface-mounted liquid soap dispenser for commercial washrooms. Its push-button valve requires no more than 5 lb. of pressure to actuate, and its gently radiused edge complements the ASI Roval Collection.
Specifications and soap requirements
- Capacity: 57 oz. (1.7 L).
- Construction: Type 304 stainless steel with satin finish.
- Overall dimensions: 5-1/2 x 10-13/16 x 4 in. [139 x 274 x 101 mm]; spout projection: 15/16 in. [24 mm].
- Valve operation: manufacturer-described as ADA compliant; requires no more than 5 lb. of pressure to actuate.
- Use liquid soap with viscosity of 1–5,500 mPa·s (cP) and pH 5.5–8.5. Avoid soaps containing reportable salts, chlorides, or alcohols.
Installation and refill
Secure the supplied concealed mounting plate to the wall or partition. The three #8 x 3/4 in. mounting screws and suitable wall anchors or other mounting system are by others. Manufacturer installation guidance places the valve-button centerline no higher than 48 in. [1219 mm] above finished floor for its stated ADA accessibility guidance; for general utility, install at 42 in. [1066 mm] above finished floor or at least 6 in. [152 mm] above a countertop.
Fill through the hinged top door, which requires the supplied special key; retain the key for future refills. A supplied locking screw secures the dispenser to its interlocking wedge bracket. Replenish the tank manually according to maintenance needs; it feeds until the soap level falls below the valve intake port.
