ASI 20200-1 TRI-Umph Hand Dryer
The ASI 20200-1 TRI-Umph is a surface-mounted, automatic hand dryer for 110–120V service, with a removable triple-filter system and owner-adjustable operating settings.
ASI Tri-Umph Hand Dryer Specs and Info Guide | Tri-Umph Cut Sheet | Tri-Umph Mounting Instructions
Filtration and finish
The removable Super Filter System uses three filter layers. The ABS cover has an antimicrobial silver-ion treatment. ASI describes the filter system as removable and replaceable when needed.
Operation and water management
Infrared sensing starts the dryer when hands enter the chamber. Air jets direct moisture toward an absorbent, evaporating ceramic plate; a drip tray collects excess water. The owner can adjust airflow and select the heater setting using the internal controls.
Key specifications
- Model: 20200-1; operating voltage: 110–120V, 50/60 Hz.
- Automatic infrared operation with 60-second automatic shutoff.
- Removable triple-filter system; ASI lists HEPA, antimicrobial and anti-odor filtration in its current technical data sheet.
- Silver-ion-treated ABS cover; silver finish.
- Dimensions: 12-11/16 in. W × 23-1/8 in. H × 7-3/4 in. D (322 × 588 × 196 mm).
- Manufacturer-listed warranty: five years.
The unit includes a concealed security screw; ASI describes its two-step security arrangement as offering enhanced resistance to unauthorized removal.
