ASI 0600-6036 60 x 36 in Angle Frame Mirror
The ASI 0600-6036 is a 60 in wide x 36 in high, surface-mounted mirror with standard 1/4 in plate-glass glazing. Its satin-finish, 18-gauge Type 304 stainless steel frame is roll-formed, interlocking, and heliarc-welded at corners polished smooth.
Mounting and glass warranty
- A concealed hanging bracket locks to the top and bottom of the frame with tamper-proof set screws; a one-piece back plate attaches to the frame with a theft-resistant locking device.
- The standard plate glass is warranted against silver spoilage for 15 years from the invoice date.
Installation guidance
Install the bracket level and plumb using #10 self-threading screws, which are by others. Hang the mirror and tighten the top and bottom locking screws. ASI's installation guidance for the 0600 series says the bottom edge of the reflecting surface should be no higher than 40 in above the finished floor for the cited ADA and ABA standards; this is manufacturer guidance, not a determination of project compliance.
