ASI 0485 Recessed Toilet Seat Cover and Toilet Tissue Dispenser
The ASI 0485 is a recessed Type 304 stainless steel combination unit for restrooms needing toilet seat covers, toilet tissue, and a removable waste can in one fixture. It holds 1,000 paper seat covers and includes a 1.3-gallon removable waste can. Confirm toilet-paper roll capacity with ASI before ordering.
Product details
- Satin-finish Type 304 stainless steel face frame, cabinet, and dispenser door.
- Seat covers self-feed until depleted; tissue rolls feed freely, with the supply level visible for low-level warning.
- A tumbler lock secures the dispenser/disposal door. The cabinet includes two supplied theft- and vandal-resistant rollers with high-impact-resistant plastic bodies and molded-in stainless steel endpins.
- Overall dimensions: 17-3/8" W x 4-1/2" D x 30-5/8" H. Required rough wall opening: 15-3/4" W x 29" H x 4" minimum depth.
- Manufacturer installation guidance places the tissue opening bottom at least 15" above the finished floor and the seat-cover opening centerline no higher than 48"; locate the tissue dispenser centerline 7" to 9" from the toilet front. An optional grab bar is not supplied.
- Manufacturer warranty: one year from invoice date.
