ASI 0034 Partition-Mounted Dual Twin Hide-A-Roll Toilet Paper Dispenser
The ASI 0034 is a through-partition dispenser designed to reduce projection into each of the two toilet compartments it serves. It holds four standard rolls or four 5-1/4-inch-diameter rolls with 1,800 sheets each. The bottom roll dispenses first; when it is depleted, the upper roll automatically drops into position.
Capacity, fit and construction
- Adjustable mounting flanges fit partitions 3/4 to 3-1/8 inches thick.
- Required partition cutout: 12-7/8 inches wide x 12-1/4 inches high.
- Type 304 stainless steel with a satin finish: 18-gauge doors, door frames and dispensing-mechanism guide tracks; 22-gauge cabinet bodies and mounting flanges.
- Accessible from either side of the partition. Each door has a tumbler lock; empty rollers cannot be removed until the door is unlocked. Reloading instructions are printed inside each door.
Installation
Mount through the precut partition opening with eight #10 x 3/4-inch screws, four per side; screws are supplied. ASI's installation guidance for ADA Accessibility Guidelines specifies a maximum unit-top height of 30 inches above the finished floor and a toilet-paper-roll centerline 7 to 9 inches in front of the commode.
