ASI 7402-BSM Surface-Mounted Toilet Tissue Holder
The ASI 7402-BSM is a single-roll, surface-mounted toilet tissue holder with a bright finish. Its Type 304 stainless steel body and spring-loaded roller hold standard-core rolls up to 6 inches in diameter.
Specifications and operation
- Dimensions: 6-5/16 inches by 6-5/16 inches.
- Construction: Type 304 stainless steel, alloy 18-8, with a bright finish.
- Roller: chrome-plated, high-impact ABS plastic; the spring-loaded spindle revolves freely and holds the roll until its core is removed.
- Capacity: one standard-core toilet tissue roll up to 6 inches in diameter.
- A theft-resistant spindle is available by adding R-009 after the model number.
- Manufacturer warranty: one year from invoice date.
Mounting guidance
For the standard surface-mount installation, drill two 7/32-inch clearance holes through tile or wallboard only. Use two #10 stainless steel screws, supplied by others, long enough to penetrate wall blocking by approximately 1/2 inch. The manufacturer also describes an optional drywall installation using suitable expansion anchors and screws supplied by others. For installations following the manufacturer’s 2010 ADA guidance, position the roller centerline 19 to 42 inches above the finished floor and 7 to 9 inches from the front of the commode.
