ASI 7308 Single Robe Hook
The ASI 7308 is a compact, surface-mounted hook for robes, clothing, or small carry bags. Its 2-5/16-inch projection keeps the hook useful without taking up unnecessary space on a restroom wall or the back of a door.
Key Features
- Type 304 stainless steel with a satin finish
- Overall dimensions: 1-15/16 inches wide x 1-15/16 inches high x 2-5/16 inches deep
- 22-gauge post with a 19-gauge mounting cup
- Suitable for robes, clothing, and small bags
- Surface-mounted design for a finished wall or door
Installation Considerations
The mounting cup attaches with the supplied screws and wall anchors or other hardware appropriate for the wall or door construction. The hook flange clips over the cup and is secured with the supplied set screw. For installations following the manufacturer’s 2010 ADA guidance, place the top of the hook no more than 48 inches above the finished floor when clear floor reach is provided.
