ASI 3815-25 Wall-to-Floor Grab Bar with Toilet Tissue Holder, 30" x 33"
This fixed configuration combines a smooth 1-1/2" O.D. type 304 stainless steel grab bar with a toilet tissue holder welded to the bar. The satin-finish snap-on cover conceals the mounting screws; the 1/8" thick mounting flange is 3-1/8" O.D. with two screw holes and three locking dimples. The cover is 22 gauge and 3-3/16" in diameter. This custom grab bar is non-returnable.
Installation coordination
The floor post projects 3" below the finished floor. The contractor must provide a suitable sleeve in the floor, 3" long, to accept the specified bar O.D. Wall fasteners and washers are by others; suitable anchoring and backing must be provided before wall finishing. ASI’s installation guidance gives a top-of-bar range of 33" to 36" above finished floor for compliance with the 2010 ADA Accessibility Standards; confirm the project’s applicable requirements and mounting conditions.
