ASI 107-14 Front-Mount Stainless Steel Mirror
The ASI 107-14 is a 12" W x 16" H one-piece formed mirror for front mounting, with a 20-gauge Type 304 stainless steel face polished to a #8 mirror finish. Its integral frame and rounded corners distinguish it from a separate framed-mirror assembly.
Verified features
- Overall dimensions: 12" W x 16" H x 1/4" D.
- Mirror and integral frame: one-piece formed, 20-gauge Type 304, alloy 18-8 stainless steel with a #8 mirror polish.
- Six mounting holes; supplied 1/4-20 x 2" pin-Torx flat-head machine screws secure the mirror to wall anchors, which are by others.
- A full-width stainless steel piano hinge is fitted at the bottom of the mirror.
- Rounded corners and a roll-formed frame with heliarc-welded, smoothly polished corners.
Mounting guidance
Install with six suitable wall anchors (by others) aligned to the mounting holes. The manufacturer's guidance for the 2010 ADA Accessibility Standards and 2015 ABA Standards specifies that the bottom edge of the reflecting surface be no higher than 40" AFF; actual installation and applicable requirements should be verified for the project.
