ASI 0391-6-1AC-41 EZ-Fill™ Automatic Soap Dispensers, Six-Pack

This pack contains six individual, hands-free dispensers, each with a translucent 33.8 oz (1 L) bottle, in matte black with AC-adapter operation. One remote control is included per six-pack. The LED indicates operation and battery condition; its low-battery indication applies when the AC adapter is not used. The standard dose is 0.03 oz (0.8 ml) per activation; the remote can program alternate dispense amounts and help prime the system.

Installation and soap

Each dispenser mounts through a 1-1/8 in. hole with an adjacent 5/32 in. hole for the anti-rotation pin. Mount the pump/control housing and bottle support under the vanity within 24 in. of the shank bottom. For AC operation, connect the adapter to a GFCI outlet under the vanity within 13.5 ft of the pump/control housing. Use liquid soap with viscosity of 100–3,800 cP and pH 5.5–8.5; avoid soaps containing reportable salts, chlorides or alcohols. Refill manually and prime with the pump button or remote as needed.
