Chicago Faucets LGF1-A12D-50 Wall-Mounted Nitrogen Fine Needle Laboratory Valve with Flange
The Chicago Faucets LGF1-A12D-50 is a wall-mounted fine needle laboratory valve designed for precise control of nitrogen (NIT) service. This single-service fitting combines a compact wall-mounted configuration with a laboratory nozzle featuring 10 serrations for a secure laboratory hose connection. A vandal-resistant 2-1/2" black nylon cross handle provides controlled manual operation, while the brown laboratory index button with white NIT lettering clearly identifies the fitting for nitrogen service. Finished in polished chrome, the LGF1-A12D-50 is a durable choice for research laboratories, schools and universities, healthcare laboratories, testing facilities, and other commercial environments requiring a dedicated wall-mounted nitrogen connection.
Key Features
- Wall-mounted single fine needle laboratory valve.
- Designed specifically for nitrogen (NIT) service.
- Single-service wall flange configuration.
- Laboratory nozzle with 10 serrations for secure laboratory hose connection.
- Vandal-resistant 2-1/2" black nylon cross handle.
- Brown laboratory index button with white NIT (Nitrogen) lettering.
- Rated operating pressure of 125 PSI maximum for nitrogen service.
- 3/8" NPT female inlet.
- 2-1/8" diameter wall flange.
- Complies with Buy American Act requirements.
- ADA ANSI/ICC A117.1 compliant.
- ANSI Z21.15b/CSA 9.1b compliant.
- Polished chrome finish.
Warranty
- 5-Year Limited Faucet Warranty
- 1-Year Limited Finish Warranty
- 5-Year Limited Mechanical Warranty
