Chicago Faucets LGF1-A12D-65 Two-Valve Nitrogen Fine Needle Laboratory Wall Fitting
The Chicago Faucets LGF1-A12D-65 is a wall-mounted laboratory fitting featuring two fine needle valves for precise control of nitrogen (NIT) service. Its Y-pattern wall flange provides two outlets positioned at 90 degrees, creating two convenient laboratory hose connection points from a single wall-mounted supply. Each valve features a laboratory nozzle with 10 serrations for a secure hose connection and a vandal-resistant 2-1/2" black nylon cross handle for controlled manual operation. Brown laboratory index buttons with white NIT lettering clearly identify the nitrogen service. Finished in polished chrome, the LGF1-A12D-65 is a durable choice for research laboratories, schools and universities, healthcare laboratories, testing facilities, and other commercial laboratory environments requiring dual nitrogen connections.
Key Features
- Wall-mounted laboratory fitting with two fine needle valves.
- Designed specifically for nitrogen (NIT) service.
- Y-pattern wall flange with two outlets positioned at 90°.
- Laboratory nozzles with 10 serrations for secure laboratory hose connections.
- Vandal-resistant 2-1/2" black nylon cross handles.
- Brown laboratory index buttons with white NIT (Nitrogen) lettering.
- Rated operating pressure of 125 PSI maximum for nitrogen service.
- 3/8" NPT male inlet.
- 1-3/4" diameter wall flange.
- Maximum mounting surface thickness of 1-3/8".
- Complies with Buy American Act requirements.
- ADA ANSI/ICC A117.1 compliant.
- ANSI Z21.15b/CSA 9.1b compliant.
- Polished chrome finish.
Warranty
- 5-Year Limited Faucet Warranty
- 1-Year Limited Finish Warranty
- 5-Year Limited Mechanical Warranty
