Chicago Faucets 1920-029KJKCP
The Chicago Faucets 1920-033JKNF is a 34-inch stainless steel braided inlet hose specifically designed for the 1920 Series Auto-Drain™ shower systems. This hose serves as the critical internal link between the shower valve outlet and the automatic drain assembly. Built with a durable stainless steel outer braid and a high-performance internal liner, it is engineered to handle the frequent pressure changes inherent in self-draining systems. As an ECAST® product, it is manufactured with lead-free materials, making it safe for use in healthcare, laboratory, and institutional environments where water purity and infection control are top priorities.
Specifications:
- Flexible stainless steel
- Inlet: 1/2"-14 NPSM female thread inlet
- Outlet: 1/2"-14 NPSM female thread outlet
Expert Insight:
The 1920-033JKNF is often confused with a standard hand spray hose, but it is actually the inlet supply hose that connects the valve to the drain manifold. Installation Tip: Because this hose is 34" long, it is designed to create a specific loop that facilitates the gravity-assisted "Auto-Drain" process. Pro Tip: When installing, ensure there are no sharp kinks or twists. If the hose is twisted during installation, it can restrict the air-gap function, preventing the system from fully purging stagnant water. If your 1920-series shower is leaking from behind the wall plate, this hose or its gaskets are usually the primary suspects. Need to verify the connection size for your specific 1920-VONF valve? Call the experts at ProDryers at 888-503-7937!
