Chicago Faucets LGF1-A12D-40 Four-Valve Nitrogen Fine Needle Laboratory Turret
The Chicago Faucets LGF1-A12D-40 is a deck-mounted laboratory turret featuring four fine needle valves for precise control of nitrogen (NIT) service. The turret provides four side outlets positioned at 90-degree intervals, creating multiple laboratory hose connection points from a single deck-mounted supply. Each valve features a laboratory nozzle with 10 serrations for a secure laboratory hose connection and a vandal-resistant 2-1/2" black nylon cross handle for controlled manual operation. Brown laboratory index buttons with white NIT lettering clearly identify the nitrogen service. Finished in polished chrome, the LGF1-A12D-40 is a durable solution for research laboratories, schools and universities, healthcare laboratories, testing facilities, and other commercial laboratory environments requiring multiple nitrogen connections.
Key Features
- Deck-mounted laboratory turret with four fine needle valves.
- Designed specifically for nitrogen (NIT) service.
- Four side outlets positioned at 90° intervals.
- Inlet supply shank for deck-mounted installation.
- Laboratory nozzles with 10 serrations for secure laboratory hose connections.
- Vandal-resistant 2-1/2" black nylon cross handles.
- Brown laboratory index buttons with white NIT (Nitrogen) lettering.
- Rated operating pressure of 125 PSI maximum for nitrogen service.
- 3/8" NPT male inlet.
- Maximum mounting surface thickness of 2-3/8".
- Complies with Buy American Act requirements.
- ADA ANSI/ICC A117.1 compliant.
- ANSI Z21.15b/CSA 9.1b compliant.
- Polished chrome finish.
Warranty
- 5-Year Limited Faucet Warranty
- Lifetime Limited Faucet Warranty
- 1-Year Limited Finish Warranty
- 5-Year Limited Mechanical Warranty
