Bobrick B-960 Fino Automatic Foam Soap Dispenser
The Bobrick B-960 is a premium, counter-mounted automatic soap dispenser from the Fino Collection, finished in high-luster Brushed Brass. This unit is specifically engineered for high-traffic commercial washrooms that require a blend of sophisticated design and heavy-duty, touchless functionality. By utilizing a patented top-fill system and high-capacity bulk soap reservoir, the B-960 significantly reduces maintenance labor while enhancing user hygiene.
Technical Specifications & Performance
- Durable Construction: Above-the-counter components are made of durable die-cast zinc with a premium Brushed Brass finish.
- High Capacity Reservoir: Includes a 34-fl oz (1.0-L) translucent, shatter-resistant high-density polyethylene soap bottle.
- Advanced Foam Technology: Employs a unique two-stage mixing process where an electronic diaphragm air pump combines air and soap into a preliminary mixture before passing it through a nylon mesh mixer cartridge in the nozzle to deliver a rich lather.
- Patented Top-Fill Design: Features a spring-loaded lid that slides forward with a concealed locking mechanism, allowing for rapid refilling using a standard Bobkey.
- Customizable Output: An integrated portion control knob allows facility managers to field-adjust the foam texture and volume.
Installation & Compatibility Requirements
- Mounting Specifications: Fits 1-3/8" (35mm) diameter mounting holes in countertops up to 2" (50mm) thick.
- Space Requirements: Requires a minimum of 18-1/2" (470mm) vertical clearance and 5" (125mm) diameter clearance below the mounting hole.
- Soap Compatibility: Optimized for commercially marketed all-purpose bulk foam soaps (non-alcohol and non-iodine based) with a viscosity under 100cP.
- Power Supply: Comes standard with a 6V AC adapter featuring a U.S. plug.
Maintenance & Intelligent Monitoring
The B-960 utilizes an integrated fiber optic system to provide real-time status updates via an LED indicator at the tip of the spout:
- Solid Green: Indicates the unit is active and currently dispensing.
- Flashing Blue: Low soap indicator, triggered when approximately 25% capacity remains.
- Flashing Red: Indicates an object remains in the activation zone, requiring the user to remove their hand to reset the sensor.
- System Flush: Includes a dedicated Flush Button in the bottom housing to facilitate routine system cleaning and maintenance.
