Bobrick B-846 Designer Series Automatic Foam Soap Dispenser in Polished Nickel
Bobrick B-846 Designer Series Counter-Mounted Automatic Foam Soap Dispenser shall dispense commercially marketed all-purpose bulk foam hand soaps, do not use iodine based or alcohol based soaps or sanitizers. Spout assembly shall be die cast zinc, with one of five finishes. Stem is integrated with spout and shall be Delrin plastic and accommodate up to 2" (50mm) thick counter tops. Unit shall be equipped with oversized funnel shape opening, covered by a 180° rotatable lid with concealed locking mechanism to allow for top filling. Unit shall have LED indicators to show unit is ready for activation. Unit shall have IR Sensor located on PC board housed in a water-resistant plastic housing. Activation Lens shall allow for defined activation range to eliminate chance of false activation during hand washing. Unit equipped with unique two stage foam mixing chambers. Air pump delivers air to foam mixer housing, combining foam soap solution and air to form a preliminary mixture of foam. Soap is then pumped through spout where a second chamber in the nozzle tip houses a mixer cartridge with nylon mesh which delivers a rich lather of foam soap. Control Dial shall allow field adjustment of foam texture. Unit shall be equipped with an Automatic System Flush Button to allow for cleaning and maintenance. Comes with 6V AC adapter.
Spec Sheet
Installation Instruction
Product Overview
The Bobrick B-846 Designer Series Automatic Foam Soap Dispenser is designed for commercial environments requiring reliable, efficient dispensing of foam hand soap. Its top-fill feature simplifies refilling, while the integrated IR sensor minimizes the chance of undesired activations. With a polished nickel finish, this dispenser not only offers functionality but also adds a touch of elegance to any restroom.
Key Features
- Top-fill design ensures easy refilling without disconnecting the unit
- Integrated IR sensor helps to reduce accidental activations
- Durable die cast zinc spout for long-lasting performance
- Adjustable foam texture control dial for customizable lather quality
- Automatic System Flush Button aids in routine maintenance and hygiene
